GLAS LLAGA

• Glass Clamp 90 Degress Glass-to-Glass are designed with a unique two-tone accent. Used to connect two fixed glass panels meeting at a 90 degree angle, or as a horizontal shelf bracket. Clamp is also designed to clamp glass panels to other glass panels or to walls.
• SPECIFICATIONS:
• Material: Solid Brass
• Glass Thickness Range: 3/8 to 1/2 Inch (10 to 12 millimeter)
• Glass Fabrication: 5/8 or 3/4 Inch (16 or 19 millimeter) hole in each panel.
• Includes: Mounting Screws and Gaskets

• Glass Clamp 180 Degress Glass-to-Glass are designed with a unique two-tone accent. Used to connect two fixed glass panels.
• SPECIFICATIONS:
• Material: Solid Brass
• Glass Thickness Range: 3/8 to 1/2 Inch (10 to 12 millimeter)
• Glass Fabrication: 5/8 or 3/4 Inch (16 or 19 millimeter) hole in each panel.
• Includes: Mounting Screws and Gaskets

• Glass Clamp 135 Degress Glass-to-Glass are designed with a unique two-tone accent. Used to connect two fixed glass panels.
• SPECIFICATIONS:
• Material: Solid Brass
• Glass Thickness Range: 3/8 to 1/2 Inch (10 to 12 millimeter)
• Glass Fabrication: 5/8 or 3/4 Inch (16 or 19 millimeter) hole in each panel.
• Includes: Mounting Screws and Gaskets

• Glass Clamp 90 Degress Glass-to-Glass are designed with a unique two-tone accent. Used to connect two fixed glass panels.
• SPECIFICATIONS:
• Material: Solid Brass
• Glass Thickness Range: (8 to 12 millimeter)
• Glass Fabrication: 5/8 or 3/4 Inch (16 or 19 millimeter) hole in each panel.
• Includes: Mounting Screws and Gaskets

• Glass Clamp 180 Degress Glass-to-Glass are designed with a unique two-tone accent. Used to connect two fixed glass panels.
• SPECIFICATIONS:
• Material: Solid Brass
• Glass Thickness Range: 3/8 to 1/2 Inch (10 to 12 millimeter)
• Glass Fabrication: 5/8 or 3/4 Inch (16 or 19 millimeter) hole in each panel.
• Includes: Mounting Screws and Gaskets

• Glass Clamp 135 Degress Glass-to-Glass are designed with a unique two-tone accent. Used to connect two fixed glass panels.

• SPECIFICATIONS:
• Material: Solid Brass
• Glass Thickness Range: 3/8 to 1/2 Inch (10 to 12 millimeter)
• Glass Fabrication: 5/8 or 3/4 Inch (16 or 19 millimeter) hole in each panel.
• Includes: Mounting Screws and Gaskets

• Glass Clamp are designed with a unique two-tone accent. Used to connect glass panels.
• Specifications:
• Material: Solid Brass
• Glass Thickness Range: 1/4 Inch (6 millimeter)
• Holes Required: Two 5/8 or 3/4 Inch (16 or 19 millimeter) Each Panel
• Includes: Gaskets and Mounting Screws

• Glass Clamp are designed with a unique two-tone accent. Used to connect glass panels.
• Specifications:
• Material: Solid Brass
• Glass Thickness Range: 1/4 Inch (6 millimeter)
• Holes Required: Two 5/8 or 3/4 Inch (16 or 19 millimeter) Each Panel
• Includes: Gaskets and Mounting Screws

• Glass Clamp are designed with a unique two-tone accent. Used to connect glass panels.
• Specifications:
• Material: Solid Brass
• Glass Thickness Range: 1/4 Inch (6 millimeter)
• Holes Required: Two 5/8 or 3/4 Inch (16 or 19 millimeter) Each Panel
• Includes: Gaskets and Mounting Screws

• Glass Clamp are designed with a unique two-tone accent. Used to connect glass panels.
• Specifications:
• Material: Solid Brass
• Glass Thickness Range: 1/4 Inch (6 millimeter)
• Holes Required: Two 5/8 or 3/4 Inch (16 or 19 millimeter) Each Panel
• Includes: Gaskets and Mounting Screws

• These Glass Brackets are designed to work with 5/16 to 3/8 inch (8 to 10 millimeter) thick glass. They may also be used as a horizontal shelf bracket. The Grande Wall Brackets have the identical configuration as the Grande Hinges which will provide continuity of design. They feature round corners and beveled edges in several decorator finishes and are constructed of solid brass.
• Specifications:
• Glass Thickness: 5/16 to 3/8 inch (8 to 10 millimeter) Tempered Safety Glass
• Construction: Solid Brass
• Holes Required: Two 3/4 inch (19 millimeter) Diameter Holes
• Includes: Gaskets and Mounting Screws

• Glass Brackets, glass to wall 90°, for vertical dividing walls, for 8 to 12 mm glass thickness.
• Specifications:
• Glass Thickness: 5/16 to 1/2 inch (8 to 12 millimeter) Tempered Safety Glass
• Construction: Solid Brass
• Holes Required: Two 3/4 inch (19 millimeter) Diameter Holes
• Includes: Gaskets and Mounting Screws

• Glass Brackets, glass to glass 90°, for vertical dividing walls,  for 8 to 12 mm glass thickness.
• Specifications:
• Glass Thickness: 5/16 to 1/2 inch (8 to 12 millimeter) Tempered Safety Glass
• Construction: Solid Brass
• Hole Required: 3/4 inch (19 millimeter) Diameter
• Includes: Gaskets

• Glass Brackets for vertical dividing walls, glass to wall 90°, made of brass, for 6 + 8 mm glass thicknesses
• Specifications:
• Glass Thickness: 1/4 to 5/16 inch (6 to 8 millimeter) Tempered Safety Glass
• Construction: Solid Brass
• Holes Required: Two 3/4 inch (19 millimeter) Diameter Holes
• Includes: Gaskets and Mounting Screws

• Glass Brackets for fixed dividing walls and bathtub partitions, glass to glass 90° made of brass, for 6 + 8 mm glass thicknesses.
• Specifications:
• Glass Thickness: 1/4 to 5/16 inch (6 to 8 millimeter) Tempered Safety Glass
• Construction: Solid Brass
• Holes Required: Two 3/4 inch (19 millimeter) Diameter Holes
• Includes: Gaskets

• Angle connectors with plastic screws, for 4 - 6 mm glass-thickness, zinc chrome plated.

• Angle connectors with plastic locking screws, angles 90 - 270°, for 5 - 8 mm glass-thickness.

• Hinge and variable connector for 5 - 8 mm thickness.

• Multi-function-connectors, with plastic screws, angle-position in each case variable, for 5 - 8 mm glass-thickness.

• Angle-connectors 90° with for 5 - 8 mm thickness.

• Connectors 135° for 5 - 8 mm thickness.

• Connector-system (Maxi) 90 -180°, with rubber-insoles as well as locking screw, zinc matt chrome.

• Connector system (mini), 90 -180°, with rubber-insoles as well as locking screw, zinc matt chrome.

• Corner Clamp, silver powder-coats, for standing dividers glass-wall, light metal, for glass-thickness 8 - 10 mm, measurement 65 x 65 mm, borehole in the glass Ø 12 mm.

• Corner Clamp for standing dividers, glass-wall, brass, for glass-thickness 6 - 8 mm, measurement 50 x 40 mm, borehole in the glass Ø 14 mm.

• Corner Clamp for standing dividers, glass-glass, brass, for glass-thickness 6 - 8 mm, measurement 50 x 40 mm, borehole in the glass Ø 14 mm.

• Angle-connectors for standing dividers, glass-wall, zinc, for glass-thickness 8 - 12 mm, measurement 58 x 45 mm, borehole in the glass Ø 18 mm.

• Corner Clamp for standing dividers, glass-glass, zinc, for glass-thickness 8 - 12 mm, measurement 58 x 45 mm, borehole in the glass Ø 18 mm.
